wireless remote control high quality small electric winch 220v
Description
The selling points of the winch are as follows:
Efficient performance: The winch has strong lifting capacity and can easily cope with the hanging and lifting needs of various heavy objects. It can complete tasks quickly and stably and improve work efficiency.
Flexibility: The winch has multiple working modes and adjustable lifting speed, making it suitable for different working environments. It can achieve horizontal and vertical lifting, as well as positioning suspension. Some winches also have a rotation function, which increases the flexibility of use.
Safety: The winch is equipped with a variety of safety protection devices, such as limit switches, overload protection, rope breakage prevention, etc., to ensure safe and reliable operation. It can improve the safety of workers and reduce the occurrence of accidents.
Durability: The winch is made of high-quality materials and sophisticated workmanship, with good durability and corrosion resistance. It can run stably for a long time, reduce the frequency of maintenance and replacement, and reduce the cost of use.
Save time and effort: The winch has a high degree of automation, is simple and convenient to operate, and reduces manual labor intensity and working hours. Using a winch can quickly lift heavy objects, saving time and labor costs. Multifunctional: The winch can be equipped with different accessories according to needs, such as hooks, clamps, etc., making it suitable for various tasks. At the same time, it can also be used in conjunction with other equipment, such as cranes, forklifts, etc., to play a greater role.
In general, winches are an ideal choice for hanging and lifting heavy objects due to their efficient performance, flexibility, safety, durability, time-saving, labor-saving, and versatility.
JM Type Electric Winch
Load Capacity:0.5-200t
Wire Rope Capacity:20-3600m
Working Speed:5-20m/min(Single Speed and Daul Speed)
Power supply:220v-690V,50Hz/60Hz,3Phase
|
Type
|
Rated Load
(kN)
|
Rated Speed
(m/min)
|
Rope Capacity
(m)
|
Rope Diameter
(mm)
|
Motor Type
|
Motor Power
(kW)
|
|
JM1
|
10
|
15
|
100
|
9.3
|
Y112M-6
|
3
|
|
JM2
|
20
|
16
|
150
|
13
|
Y160M-6
|
7.5
|
|
JM5
|
50
|
10
|
270
|
21.5
|
YZR160L-6
|
11
|
|
JM8
|
80
|
8
|
250
|
26
|
YZR180L-6
|
15
|
|
JM10
|
100
|
8
|
170
|
30
|
YZR200L-6
|
22
|
|
JM16
|
160
|
10
|
500
|
37
|
YZR250M2-8
|
37
|
|
JM20
|
200
|
10
|
600
|
43
|
YZR280S-8
|
45
|
|
JM25
|
250
|
9
|
700
|
48
|
YZR280M-8
|
55
|
|
JM32
|
320
|
9
|
700
|
56
|
YZR315S-8
|
75
|
|
JM50
|
500
|
9
|
800
|
65
|
YZR315M-8
|
90
|
JK Type Electric Winch
Load Capacity:0.5-60t
Wire Rope Capacity:20-500m
Working Speed:20-35m/min(Single Speed and Daul Speed)
Power supply:220v-690V,50Hz/60Hz,3Phase
|
Basic Parameters
|
Rated Load
|
Average Speed of Rope
|
Capacity of Rope
|
Rope Diameter
|
Electromtor Power
|
Overall Dimension
|
Total Weight
|
|
Model
|
KN
|
m/min
|
m
|
mm
|
KN
|
mm
|
kg
|
|
JK0.5
|
5
|
22
|
190
|
7.7
|
3
|
620×701×417
|
200
|
|
JK1
|
10
|
22
|
100
|
9.3
|
4
|
620×701×417
|
300
|
|
JK1.6
|
16
|
24
|
150
|
12.5
|
5.5
|
945×996×570
|
500
|
|
JK2
|
20
|
24
|
150
|
13
|
7.5
|
945×996×570
|
550
|
|
JK3.2
|
32
|
25
|
290
|
15.5
|
15
|
1325×1335×840
|
1011
|
|
JK5
|
50
|
30
|
300
|
21.5
|
30
|
1900×1620×985
|
2050
|
|
JK8
|
80
|
25
|
160
|
26
|
45
|
1533×1985×1045
|
3000
|
|
JK10
|
100
|
30
|
300
|
30
|
55
|
2250×2500×1300
|
5100
|
Transport
PACKING AND DELIVERY TIME
We have a complete production security system and experienced workers to ensure timely or early delivery.
R & D
Professional power.
BRAND
Strength ofthe factory.
PRODUCTION
Years ofexperience.
CUSTOM
Spot isenough.
Asia
10-15days
Middle East
15-25days
Africa
30-40days
Europe
30-40days
America
30-35days
By National Station exporting standard plywood box,wooden palletor in 20ft & 40ft Container.Or as per your demands.
